520M40 Poob Wax Peev Castings
520M40 yog cov hlau alloy uas muaj zog heev uas nws cov tshuaj muaj pes tsawg leeg yog tsim los ntawm cov ntsiab lus xws li carbon, chromium, molybdenum, thiab manganese.
Khoom Taw Qhia
|
520M40 Poob Wax Peev Castings |
|||||||
|
Yam khoom |
Khoom siv |
Txheej txheem ntau lawm |
Sintering kub |
Pwm |
Kev cai |
||
|
520M40 Poob Wax Peev Castings |
520M40 |
Txhaj tshuaj molding |
1380 degree |
Yuav tsum customized |
Yog lawm |
||
|
Cov ntaub ntawv muaj |
Carbon steel, hlau alloy, aluminium alloy, qis carbon stainless hlau, titanium alloy (Ti, TC4), tooj liab alloy, kub alloy (718, 713) |
||||||
|
Smoothness |
Dimensional raug |
Khoom ntom ntom |
Cov tsos mob kho |
Tsim nyog hnyav |
|||
|
Roughness 1-5μm |
(±0.1%-±0.5%) |
7.8g / cm³ |
Raws li cov neeg siv khoom xav tau |
3g -8kg) |
|||
520M40 yog cov hlau alloy uas muaj zog heev uas nws cov tshuaj muaj pes tsawg leeg yog tsim los ntawm cov ntsiab lus xws li carbon, chromium, molybdenum, thiab manganese. 520M40 steel muaj lub zog siab, hardness, thiab corrosion kuj, nrog rau cov khoom siv zoo thiab tawv. Cov hlau tuaj yeem txhim kho nws cov khoom los ntawm cov txheej txheem kho cua sov xws li normalizing thiab quenching.
Daim ntawv thov
520M40 Poob Wax Investment Castings feem ntau yog siv los tsim cov khoom siv dag zog siab, cov kabmob, cov hniav, lub zog, thiab lwm yam khoom hnyav, thiab tau siv dav hauv aviation, tsheb, nkoj, thiab lwm yam. Nrog kev tshwm sim tsis tu ncua ntawm cov thev naus laus zis tshiab thiab cov ntaub ntawv tshiab, daim ntawv thov kev lag luam thiab kev cia siab ntawm 520M40 steel yuav txuas ntxiv mus.
Nws yuav tsum raug sau tseg tias thaum siv thiab ua 520M40 steel, cov txheej txheem tsim nyog thiab cov khoom siv yuav tsum tau siv los xyuas kom meej nws qhov zoo thiab kev ua tau zoo. Tsis tas li ntawd, vim lub siab hardness ntawm 520M40 steel, nws yog ib qho nyuaj rau txheej txheem thiab tsis haum rau high-precision ua xws li milling.
Qhov zoo: siab zog, hardness, zoo corrosion kuj, zoo mechanical zog, tshav kub kho.
Disadvantages: Tsis yooj yim rau kev ua thiab nqaim ntawm daim ntawv thov.
Cov tshuaj muaj pes tsawg leeg: carbon ({{0}}.36% 0.44%), chromium (0.60% {{10} }}.90%), molybdenum (0.15% 0.25%), manganese (0.50% 0.80%).
Lub cev muaj zog: Qhov ceev yog 7.84g / cm³, melting point yog 1420 ~ 1460 degree.
Mechanical zog: tensile zog yog hais txog 780MPa, yield zog yog hais txog 515MPa, thiab elongation yog 14% ~ 17%. Tom qab normalizing lossis quenching kev kho cua sov, lub zog tuaj yeem txhim kho ntxiv.
