Aluminium bronze dej meter yeeb nkab poob ciab peev castings
Yam khoom	Khoom siv	Txheej txheem ntau lawm		Sintering kub		Pwm	Kev cai
Aluminium bronze dej meter yeeb nkab poob ciab peev castings		peev casting		1380 degree		Yuav tsum customized	Yog lawm
Cov ntaub ntawv muaj	Cov pa roj carbon tsawg, hlau alloy, aluminium alloy, qis-carbon stainless hlau, titanium alloy (TI, TC4), tooj liab alloy, siab kub alloy (718, 713)
Smoothness	Dimensional raug		Khoom ntom ntom		Cov tsos mob kho		Tsim nyog hnyav
Roughness 1-5μm	(±0.1%-±0.5%)		7. 3-7.6g/CM³		Raws li cov neeg siv khoom xav tau		0.03g-400g

Poob ciab peev casting ntawm txhuas bronze dej meter yeeb nkab fittings

ZB15W tshwj xeeb rooj vag li qub rau bronze, txhuas bronze thiab npib tsib xee-aluminium bronze dej ntsuas nrog cov xov sab hauv.

product-800-800

Specification parameter

Qauv: ZB15W-16T

Qeb: bronze rooj vag valve, aluminium bronze rooj vag valve, nickel-aluminium bronze rooj vag valve

Structure: Internal xov rooj vag valve, teb lifting qws rooj vag valve

Plhaub: tooj liab, txhuas bronze, tin bronze, nickel-aluminium bronze

Sealing: tetrafluoroethylene PTFE, bronze, txhuas bronze, npib tsib xee-aluminium bronze, surfacing hlau-raws li alloy, surfacing cemented carbide, hlau-raws li alloy.

Siab: Tsawg dua lossis sib npaug li 1.6 MPa

Kub: -196 ~ 525 degree

Muaj nuj nqi: Seawater, polycarbonate, polyethylene, tsawg ntom polyethylene, aromatic hydrocarbon, liquefied natural gas (LNG).

Standards: MSS-SP-80-1997, BS 5154-1999, JIS B 2023-1999, JIS B 2013-1999, JIS B 2011-1999.

Cov xov ntawm cylindrical yeeb nkab ua raws li ISO228-1991.

Tapered yeeb nkab xov ua raws li ANSI B1.20.1-1994.

Chaw tsim tshuaj paus: Qinhuangdao Zhongwei Precision Parts Co., Ltd.

Khoom nta

Flow channel: ncaj qha mus; Kev sib txuas ntawm lub cev lub cev thiab lub kaus mom: cov xov sab hauv; Txuas kawg: xov; Ram: ib leeg ib leeg

ZB15W-16T bronze, aluminium bronze thiab npib tsib xee-aluminium bronze rooj vag li qub feem ntau yog siv rau hauv kev ua haujlwm hnyav uas yuav tsum tau kov yeej ib puag ncig muaj zog, xws li seawater desalination platforms, ntau yam seagoing nkoj, warships, submarines, offshore drilling platforms thiab lwm yam khoom siv navigation; Thiab txhawb cov chaw rau polycarbonate, polyethylene, low density polyethylene, aromatic hydrocarbon thiab liquefied natural gas (LNG) refineries. Tam sim no nws tau siv dav hauv kev tua hluav taws, kev tswj hwm ballast, cua txias system, dej hiav txwv txhaj tshuaj thiab ntau lwm yam tseem ceeb.

Main kev ua haujlwm ntau yam

Qauv	PN	Ua haujlwm siab / MPa	Siv tau qhov kub thiab txias / degree	Siv tau nruab nrab

ZB15W-16T	16	1.6	-196 ~ 525 degree	Seawater, polycarbonate, polyethylene, Tsawg ntom polyethylene, Aromatic hydrocarbons, liquefied natural gas (LNG)

Cov duab thiab qhov sib txuas loj

product-225-206

Dej inlet × dej qhov hluav taws xob mm × mm	Rp/hauv	L1	L2	d	H	Ua
Dej inlet × dej qhov hluav taws xob mm × mm	Rp/hauv	L1	L2	d	H	Ua
15×15	Rp 1/2	97	110	15±0.12	72	55
20×15	Rp3/4	107	120	15±0.12	83	65
20×20	Rp3/4	107	120	20±0.12	83	65
25×20	Rp1	117	130	20±0.12	96	75

Cov khoom siv tseem ceeb

Qauv	Khoom siv
	Valve lub cev, lub kaus mom, qia	Lub nplhaib sealing	Ntim	Handwheel
ZB15W-16T	Bronze, txhuas bronze, tin bronze, npib tsib xee-aluminium bronze	Nitrile roj hmab NBR	Tom ntej: tetrafluoroethylene PTFE	nrum hlau
		Bronze, txhuas bronze, tin bronze, npib tsib xee-aluminium bronze
		Tom ntej: tetrafluoroethylene PTFE

Lus Cim: Copper / bronze yog cov khoom siv hlau alloy, uas tseem hu ua aluminium bronze, npib tsib xee-aluminium bronze, bronze rau chav lossis li qub, cov bronze sib xyaw thiab cov tooj liab siab. Saib daim ntawv txuas rau cov qib tshwj xeeb.

Bronze	ASTM B 62 =UNS C83600
	BS1400: LG2
	TS EN 1982: CC491K
	BS1400 LG4
	TS EN 1982 CC492K
	ASTM B148 10 alloys nyob rau hauv tag nrho
	ASTMB 61=UNS C92200
Aluminium bronze	QAl{0}} (GB/T 4423-2007替代GB/T 4429-1987) )
	QAl{0}} (GB/T 4423-2007替代GB/T 4429-1987) )
	ZCuA19Mn2(GB-T1176-1987)
	ZCuAl10Fe3(GB-T1176-1987)
Tin tooj	ASTM B143-A110y No.1B/ZCuSn8Zn4
	ASTM B143-A110y No.1A/ZCuSn10Zn2
	ASTM B62-'52/ ZCuSn5Zn5.5
Nickel-aluminium bronze	ASTM B148 UNS C83600 Cov Lus Qhia
	ASTM B148 UNS C95400 Cov Lus Qhia
	ASTM B148 UNS C95500 Cov Lus Qhia
	ASTM B148 UNS C95800 (BS1400: AB2)
	ASTM B148 UNS C95900 Cov Lus Qhia
	ASTM B148 10 alloys nyob rau hauv tag nrho
	TS EN 1982 CC333G

Kev ceev faj rau kev yuav khoom

Cov kev qhia tshwj xeeb thiab cov qauv ntawm ZB15W tshwj xeeb rooj vag li qub rau cov xov tooj hauv xov tooj, aluminium bronze thiab nickel-aluminium bronze dej ntsuas tau qhia hauv nplooj ntawv no, suav nrog cov qauv, qauv duab, qhov ua tau zoo thiab qhov ntev ntawm kev teeb tsa, yog rau siv xwb. Rau cov ncauj lus kom ntxaws specifications thiab cov nqi ntawm ZB15W tshwj xeeb rooj vag li qub rau cov xov tooj tooj liab, txhuas bronze thiab npib tsib xee-txheej tooj liab tooj liab dej ntsuas, thov hu rau peb kom nug. Nyob rau hauv qhov kev pom ntawm qhov txwv kev hloov kho theem, kev ua yuam kev thiab qhov tsis txaus ntseeg yog qhov tsis muaj, thov kho kuv.

Peb yog cov chaw tsim khoom ntawm Aluminium bronze dej meter yeeb nkab poob ciab peev castings, yog tias koj xav tau cov ntaub ntawv ntxiv thov hu rau peb!
